 Quick start code 2 (Initial setting code)
Quick start code 2 tells the factory to ship with each parameter preset to the values detailed as specified by
the customer. Quick start code is not necessarily specified when ordering, unless the preset is requested.
These parameters are software selectable items and can be re-programmed in the field via the manual.
Specifications
Quick start code 2 (Initial setting code)
(1) (2) (3) (4) (5) (6) (7)
        
DI assignment DI1 to DI6 [Refer to DI Assignment Code Table (P. 1-7)] 
Digital output 1 Event 1 [Deviation high] N
(DO1) Assign other DO type [Refer to DO Type Code Table (P. 1-8)] 
Digital output 2 Event 2 [Deviation low] N
(DO2) Assign other DO type [Refer to DO Type Code Table (P. 1-8)] 
Digital output 3 Time signal 1 N
(DO3) Assign other DO type [Refer to DO Type Code Table (P. 1-9)] 
Digital output 4 Pattern end signal N
(DO4) Assign other DO type [Refer to DO Type Code Table (P. 1-9)] 
No CT1 and CT2 N
CT1: CTL-6-P-N CT2: No use P
CT type CT1: CTL-12-S56-10L-N CT2: No use S
CT1: CTL-6-P-N CT2: CTL-6-P-N T
CT1: CTL-12-S56-10L-N CT2: CTL-12-S56-10L-N U
Communication 1
protocol
None
N
RKC communication (ANSI X3.28-1976) 1
Modbus 2
Factory set value of DO5 through DO12 (optional) is Time signal.
 DI Assignment Code Table
(DI1 to DI6: Optional DI7 to DI11: Standard function)
DI number
Code (0 to 5)
0 1 2 3 4 5
Digital input 1 (DI1) PTN1 PTN1 WAIT release WAIT release WAIT release WAIT release
Digital input 2 (DI2) PTN2 PTN2 WAIT release WAIT release WAIT release WAIT release
Digital input 3 (DI3) PTN4 PTN4 WAIT release WAIT release WAIT release WAIT release
Digital input 4 (DI4) PTN8 PTN8 WAIT release WAIT release WAIT release WAIT release
Digital input 5 (DI5) PTN16 PTN16 WAIT release WAIT release WAIT release WAIT release
Digital input 6 (DI6) P. SET P. SET WAIT release WAIT release WAIT release WAIT release
Digital input 7 (DI7) RESET RESET PTN1 PTN1 RESET RESET
Digital input 8 (DI8) RUN RUN PTN2 PTN2 RUN RUN
Digital input 9 (DI9) STEP STEP PTN4 PTN4 STEP STEP
Digital input 10 (DI10) HOLD PTN32 PTN8 PTN8 HOLD HOLD
Digital input 11 (DI11) PTN32 PTN64 P. SET PTN16 Direct/Reverse PTN_INC
PTN1, 2, 4, 8, 16, 32, 64: Pattern number switch STEP: Step (STEP) function
P. SET: Pattern set HOLD: Hold (HOLD) function
WAIT release: Wait state release Direct/Reverse: Direct/Reverse action switching
RESET: Reset mode (RESET) setting PTN_INC: Pattern increment
RUN: Program control mode (RUN) setting
