1. OUTLINE
IMR02L04-E3
1-8
 DO Type Code Table
Digital output 1 (DO1)
Code Type Code Type Code Type
N None L Event 1 process low
with hold action
1 Event 1 manipulated output value
(MV1) high [heat-side]
A Event 1 deviation high P Heater break alarm 1 (HBA1) 2 Event 1 manipulated output value
(MV1) low [heat-side]
B Event 1 deviation low Q Heater break alarm 2 (HBA2) 3 Event 1 manipulated output value
(MV2) high [cool-side]
C Event 1 deviation high/low R Control loop break alarm (LBA) 4 Event 1 manipulated output value
(MV2) low [cool-side]
D Event 1 band S FAIL (de-energized fixed) 5 Time signal 1
E Event 1 deviation high
with hold action
T Feedback resistance (FBR) input
error
6 Time signal 2
F Event 1 deviation low
with hold action
U Event 1 band
(High/Low individual setting)
7 Time signal 3
G Event 1 deviation high/low
with hold action
V Event 1 set value (SV) high 8 Time signal 4
H Event 1 process high W Event 1 set value (SV) low 9 Pattern end signal
J Event 1 process low X Event 1 deviation high/low
(High/Low individual setting)
K Event 1 process high
with hold action
Y Event 1 deviation high/low
with hold action
(High/Low individual setting)
Digital output 2 (DO2)
Code Type Code Type Code Type
N None L Event 2 process low
with hold action
1 Event 2 manipulated output value
(MV1) high [heat-side]
A Event 2 deviation high P Heater break alarm 1 (HBA1) 2 Event 2 manipulated output value
(MV1) low [heat-side]
B Event 2 deviation low Q Heater break alarm 2 (HBA2) 3 Event 2 manipulated output value
(MV2) high [cool-side]
C Event 2 deviation high/low R Control loop break alarm (LBA) 4 Event 2 manipulated output value
(MV2) low [cool-side]
D Event 2 band S FAIL (de-energized fixed) 5 Time signal 1
E Event 2 deviation high
with hold action
T Feedback resistance (FBR) input
error
6 Time signal 2
F Event 2 deviation low
with hold action
U Event 2 band
(High/Low individual setting)
7 Time signal 3
G Event 2 deviation high/low
with hold action
V Event 2 set value (SV) high 8 Time signal 4
H Event 2 process high W Event 2 set value (SV) low 9 Pattern end signal
J Event 2 process low X Event 2 deviation high/low
(High/Low individual setting)
K Event 2 process high
with hold action
Y Event 2 deviation high/low
with hold action
(High/Low individual setting)
