RKC INSTRUMENT PF900 User Manual

4. BASIC OPERATION
IMR02L04-E3
4-26
 Parameter list [Batch setting type]
Refer to P. 4-27 and P. 4-28 to switch parameter setting display.
Name Symbol Data range
Factory set
value
Program setting block (
PROG
)
Setting pattern number
PTN.NO
1 to 99 (Within the maximum pattern number)
1
Segment level
LEVEL
Setting limiter low to Setting limiter high
0
Segment time
TIME
From 0:00 to 500:00 (Hour: Minute), or
from 0:00 to 500:00 (Minute: Second)
0 hour
00 minute
PID memory group number
PID.GR
0 to 8
0: Level PID
0
Event memory group number
EV.GR
0 to 8
0: Event OFF
1
Wait memory group number
WT.GR
0 to 8
0: Wait OFF
1
Segment signal *
SIGNL
0: OFF 1: ON
00000000 Value at SV display
Segment signal 1
Segment signal 2
Segment signal 3
Segment signal 4
Segment signal 5
Segment signal 6
Segment signal 7
Segment signal 8
00000000
Segment repeat start/end number
ST‹ED
Start number: 1 to 99
End number: 1 to 99
Within the maximum segment number.
1
Segment repeat execution time
RPT.SG
1 to 9999 times
1: No segment repeat
1
Pattern repeat execution time
RPT.PN
1 to 10000 times
1: No pattern repeat
10000: No limit
1
Link pattern number
LNK.PN
0 to 99 (Within the maximum pattern number)
0: No pattern link
0
Pattern end output duration
END.TM
From 0:00 to 500:00 (Hour: Minute), or
from 0:00 to 500:00 (Minute: Second)
Output remains ON at 0:00 (Hour: Minute or Minute: Second)
0 hour
00 minute
Time signal memory group number
P TS.GR
0 to 16
0: No assignment
1
Output program memory group
number
P.MV.GR
0 to [128/Maximum number of segments]
Up to 99
0: No assignment
0
PID memory group setting block (
PID
)
Refer to the parameter list of Partial setting type for the PID memory group setting block or the latter setting blocks of
Batch setting type (P. 4-18).
* Displayed when the Segment signal type is selected.
 Press the

key to switch setting screen.
 Setting block may be switched by using the

key or the

key.
 Press the STEP R.SET key to go back to the previous display.
 Press the STEP R.SET key while pressing the

key to go back to
the first setting display of the setting block.
PV/SV monitor
Parameter setting mode
Press and hold the  key for
2 seconds or more.
Press the

key or Press the

key while pressing the

key.
