RKC INSTRUMENT PF900 User Manual

6. PROGRAM CONTROL
IMR02L04-E3
6-2
6.1 Memory Group
PID values, Event, Wait, Time signal and Output program can be stored in a memory group.
A Memory group is set by segment or pattern.
 Memory group to be set by segment
PID memory group: Number of group: Up to 8 groups
Setting items: PID memory group number Output limiter high (MV1)
Proportional band [heat-side] Output limiter low (MV1)
Integral time [heat-side] Output limiter high (MV2)
Derivative time [heat-side] Output limiter low (MV2)
Control response parameter ON/OFF action differential gap
Proportional band [cool-side] (upper)
Integral time [cool-side] ON/OFF action differential gap
Derivative time [cool-side] (lower)
Overlap/Deadband Control loop break alarm (LBA)
Open/Close output neutral zone time
Manual reset LBA deadband (LBD)
Event memory group: Number of group: Up to 8 groups
Setting items: Event memory group number
Event 1 set value (EV1)/Event 1 set value (EV1) [high]
Event 1 set value (EV1’) [low]
Event 2 set value (EV2)/Event 2 set value (EV2) [high]
Event 2 set value (EV2’) [low]
Event 3 set value (EV3)/Event 3 set value (EV3) [high]
Event 3 set value (EV3’) [low]
Event 4 set value (EV4)/Event 4 set value (EV4) [high]
Event 4 set value (EV4’) [low]
Wait memory group: Number of group: Up to 8 groups
Setting items: Wait memory group number Wait release trigger selection
Wait zone high Wait time-out set value
Wait zone low
 Memory group to be set by pattern
Time signal memory group:
Number of group: Up to 16 groups (Up to 16 memories for each group)
Setting items: Time signal memory group number
Time signal output assignment
Start segment of time signal
Time signal start time
End segment of time signal
Time signal end time
Output program memory group:
Number of group: 128/Maximum number of segments (Up to 99)
Maximum number of segments:
Number of pattern  Number of segments
Setting items: Output program memory group number
Output program value 1
Output program value 2
Output program value 3
(P. 4-18)
(P. 4-19)
(P. 4-19)
(P. 4-20)
(P. 4-20)
