6. PROGRAM CONTROL
IMR02L04-E3
6-28
6.11 Edit Function
Copy and Data clear are available for edit function.
Pattern copy or Data clear is only available at the Reset mode (RESET).
6.11.1 Description of function
Pattern copy
All set values of a pattern may be copied to another pattern.
Segment copy
Within a pattern, settings of the previous segment may be copied to the next segment.
To copy the setting data of the previous segment, press the
key and the
key at the same time at
parameter setting display of the next segment.
Items to be copied: Segment level, Segment time, PID memory group number, Event memory group
number, Wait memory group number, Segment signal
Data clear
Set values at the Parameter setting mode and Tag name may be initialized based on the set values such as
Input types, and Decimal point position being set in the Engineering mode.
6.11.2 Parameter setting
Pattern copy [Parameter setting mode: Editing block]
Set copy source pattern number and copy destination pattern number.
Parameter symbol Data range Factory set value
COPY
Copy source number: 0 to 99
Copy destination number: 0 to 99
Within the maximum pattern number.
0
Data clear [Parameter setting mode: Editing block]
Parameter symbol Data range Factory set value
CLR
All set values in the Parameter setting mode will be initialized after setting 9999
and switching from NO to YES.
0
