1. OUTLINE
IMR02L04-E3
1-5
Output Code Table
Output type Code Output type Code
Voltage (0 to 1 V DC) Available for OUT3 only 3 Voltage (1 to 5 V DC) 6
Voltage (0 to 5 V DC) 4 Current (0 to 20 mA DC) 7
Voltage (0 to 10 V DC) 5 Current (4 to 20 mA DC) 8
Range Code Table
Thermocouple (TC) input [voltage (low) group]
Type Code Measured range Code Measured range
K
K02 0 to 400 C KA4 0.0 to 800.0 F
K06 0 to 1200 C KB4 0.0 to 2400.0 F
K09 0.0 to 400.0 C KC5 328 to 2502 F
K23 0.0 to 1300.0 C KC9 328.0 to 2502.0 F
K35 200.0 to
400.0 C
K41 200 to +1372 C
K42 200.0 to
1372.0 C
J
J15 200 to
1200 C JB5 0.0 to 2100.0 F
J16 0.0 to 1200.0 C JB6 0.0 to 800.0 F
J27 200.0 to
400.0 C JB9 328 to 2192 F
J29 200.0 to
1200.0 C JC9 328.0 to 2192.0F
T
T06 0.0 to 400.0 C TA7 0.0 to 700.0 F
T13 200.0 to
200.0 C TB7 300.0 to 700.0 F
T16 200 to
400 C TC2 328.0 to 752.0 F
T19 200.0 to
400.0 C TC9 328 to 752 F
E
E06 200 to
1000 C EA6 0.0 to 1800.0 F
E08 0.0 to 1000.0 C EB1 328 to 1832 F
E17 200.0 to
200.0 C EB3 328.0 to 1832.0 F
E20 200.0 to
1000.0 C
L
L04 0.0 to 900.0 C LA3 0 to 1652 F
L05 0 to 900 C LA6 0.0 to 1600.0 F
LB1 0.0 to 1652.0 F
U
U04 0.0 to 600.0 C UB1 0.0 to 1100.0 F
U08 0 to 600 C UB3 0.0 to 1112.0 F
UB4 0 to 1112 F
N
N02 0 to 1300 C NA4 0.0 to 2300.0 F
N05 0.0 to 1300.0 C NA7 0 to 2372 F
NA8 0.0 to 2372.0 F
R
R05 0.0 to 1700.0 C RA5 0.0 to 3200.0 F
R07 50 to
1768 C RA7 58 to 3214 F
R08 50.0 to
1768.0C RA8 58.0 to 3214.0 F
S
S04 0.0 to 1700.0 C SA5 0.0 to 3200.0 F
S06 50 to
1768 C SA7 58 to 3214 F
S07 50.0 to
1768.0 C SA8 58.0 to 3214.0 F
B
B03 0 to 1800 C BA9 0.0 to 3200.0 F
B04 0.0 to 1800.0 C BB2 0 to 3272 F
BB3 0.0 to 3272.0 F
W5Re/W26Re
W03 0 to 2300 C WA2 0 to 4200 F
W04 0.0 to 2300.0 C WA6 0.0 to 2200.0 F
W06 0.0 to 1200.0 C WA8 0.0 to 4200.0 F
PLII
A02 0 to 1390 C AA2 0 to 2534 F
A05 0.0 to 1300.0 C AA5 0.0 to 2300.0 F
A06 0.0 to 1390.0 C AA7 0.0 to 2534.0 F
PR40-20
F01 0.0 to 1800.0 C FA1 0.0 to 3200.0 F
F02 0 to 1800 C FA2 0 to 3200 F
To Next Page
