4. BASIC OPERATION
IMR02L04-E3
4-38
Continued from the previous page.
Name Symbol Data range
Factory set
value
OUT3 transmission output scale low
ALS3
Varies with OUT3 assignment.
The data range is the same as the OUT2 transmission output scale low.
Function block 34 (F34.01 to F34.12)
DO1 assignment
LDO1
0: None
1 to 8: Time signal 1 to Time signal 8
9 to 12: Event 1 to Event 4
13: HBA1
14: HBA2
15: Logical OR of HBA1 and HBA2
16: LBA
17: Input error state
18: Program control mode (RUN) state
19: Fixed set point control mode (FIX) state
20: Manual control mode (MAN) state
21: Ramp state
22: Soak state
23: Hold state
24: Wait state
25: Pattern end signal
26: Autotuning (AT) state
27: FAIL state
28: Host communication error
29: Intercontroller communication error
30: Feedback resistance (FBR) input error
Based on
model code.
When not
specifying:
DO1: 9
DO2: 10
DO3: 1
DO4: 25
DO2 assignment
LDO2
DO3 assignment
LDO3
DO4 assignment
LDO4
DO5 assignment
LDO5
When
specifying 12
points of DO
at ordering:
DO5 to DO12:
1 to 8
When
specifying 4
points of DO
at ordering:
DO5 to DO12:
0
DO6 assignment
LDO6
DO7 assignment
LDO7
DO8 assignment
LDO8
DO9 assignment
LDO9
DO10 assignment
LDO10
DO11 assignment
LDO11
DO12 assignment
LDO12
Function block 41 (F41.01 to F41.08)
Event 1 type
ES1
0: None
1: Deviation high
1
2: Deviation low
1
3: Deviation high/low
1
4: Deviation high/low (Individual high and low setting)
1
5: Band
1
6: Band (Individual high and low setting)
1
7: Process high
1
8: Process low
1
9: SV high
10: SV low
11: MV1 high [heat-side]
1, 2
12: MV1 low [heat-side]
1, 2
13: MV2 high [cool-side]
1
14: MV2 low [cool-side]
1
1
Event hold action is available.
2
If there is Feedback resistance (FBR) input in Position
proportioning PID control, set to the FBR input value.
Based on
model code.
When not
specifying: 1
Event 1 hold action
EHO1
0: OFF
1: Hold action ON
[when power turned on; when Event start (SV changed)]
Based on
model code.
When not
specifying: 0
Event 1 differential gap
EH1
Deviation, process or set value:
0 to Input span (Unit: C [F])
MV: 0.0 to 110.0 %
TC/RTD: 2
V/I: 0.2
MV: 0.2
Event 1 output action at input error
EBO1
0 to 4 0
When PV reaches Input
error determination point
(high) or higher
temperature:
When PV reaches Input
error determination point
(low) or lower
temperature:
0 Confor
s to Event action Confor
s to Event action
1 ON Confor
s to Event action
2 Confor
s to Event action ON
3ON ON
4 OFF OFF
Event 1 timer
EVT1
0.0 to 600.0 seconds 0.0
Continued on the next page.
