RKC INSTRUMENT PF900 User Manual

4. BASIC OPERATION
IMR02L04-E3
4-39
Continued from the previous page.
Name Symbol Data range
Factory set
value
Event 1 interlock
EIL1
0: Unused
1: Used
2: Activate Interlock and switch to the Manual control
mode to produce Manipulated output at Input error.
0
Event 1 minimum ON time
E1ON
0.0 to 600.0 seconds 0.0
Event 1 minimum OFF time
E1OFF
0.0 to 600.0 seconds 0.0
Function block 42 (F42.01 to F42.08)
Event 2 type
ES2
The data range is same as Event 1 type.
Based on
model code.
When not
specifying: 2
Event 2 hold action
EHO2
The data range is same as Event 1 hold action.
Based on
model code.
When not
specifying: 1
Event 2 differential gap
EH2
The data range is same as Event 1 differential gap.
Event 2 output action at input error
EBO2
Event 2 timer
EVT2
Event 2 interlock
EIL2
Event 2 minimum ON time
E2ON
Event 2 minimum OFF time
E2OFF
Function block 43 (F43.01 to F43.08)
Event 3 type
ES3
The data range is same as Event 1 type.
Based on
model code.
When not
specifying: 0
Event 3 hold action
EHO3
The data range is same as Event 1 hold action.
Based on
model code.
When not
specifying: 0
Event 3 differential gap
EH3
The data range is same as Event 1 differential gap.
Event 3 output action at input error
EBO3
Event 3 timer
EVT3
Event 3 interlock
EIL3
Event 3 minimum ON time
E3ON
Event 3 minimum OFF time
E3OFF
Function block 44 (F44.01 to F44.08)
Event 4 type
ES4
The data range is same as Event 1 type.
Based on
model code.
When not
specifying: 0
Event 4 hold action
EHO4
The data range is same as Event 1 hold action.
Based on
model code.
When not
specifying: 0
Event 4 differential gap
EH4
The data range is same as Event 1 differential gap.
Event 4 output action at input error
EBO4
Event 4 timer
EVT4
Event 4 interlock
EIL4
Event 4 minimum ON time
E4ON
Event 4 minimum OFF time
E4OFF
Continued on the next page.
