3-18 Frame 3A and 3B Installation
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Figure 3.18 Locations for Frame 3A Complete Drive Power Module Bay Control,
Ground, Motor Output, and Coolant Connections
Dimensions are in millimeters and (inches).
536 (21.09)
P1 & P2
559 (22.00)
TB5
24 (0.94)
Backplane of Power
Module Chassis.
Top Anti-sway
Bracket
249 (9.82)
P1
175 (6.89) GRD
142 (5.58) U/V/W
192 (7.58)
119 (4.67)
119 (4.67)
210 (8.25)
GRD
P1
P2
1365 (53.75)
1226 (48.27)
P1
1166 (45.92)
P2
862 (33.92)
262 (10.30)
62 (2.43)
168 (6.62)
Bottom Anti-sway
Bracket
Power Module
Status Indicators
Converter/Inverter
Power Module
Cutaway of Bottom Cover
Showing P1 and P2
Cutaway of Bottom Cover
Showing TB5
Outlet
Inlet
Outlet
Inlet
Right Wall
Cutaway
Ø22 (Ø0.88) through
Knockout Size 1/2 inch
in Right Wall for Cooling
Loop Equipment Wiring
90 (3.56)
132 (5.18)
97 (3.81)
174 (6.87)
391 (15.38)
90 (3.56)
See Figure 3.4 and Figure 3.20
for Inlet, Outlet, PE, and Motor
Lead Depth Dimensions
To Next Page
