Timer A Prescaler Register (TAPS)
E3H, Set1, Bank1, R/W
LSBMSB.7.6.5.4.3.2.1.0
Reset Value: FFh
Timer A clock source selection bit
0 = Internal clock source
1 = External clock source from TACK
Not used for S3F84B8
Timer A prescaler bit (TAPSB)
TA CLK = fxx/(2^TAPSB)
NOTE: Prescaler values(TAPSB) above 12 are not valid.
Figure 11-2 Timer A Prescaler Register (TAPS)
Timer A Data Register (TADATA)
E3H, Set1, Bank1, R/W
LSBMSB.7.6.5.4.3.2.1.0
Reset Value: FFh
Figure 11-3 Timer A DATA Register (TADATA)
