PLC-HP7000L Expand Serial Command Functional Specifications
33/94
8.7 Screen Control Command
8.7.1 CF_SCREEN Command
Command
“CF_SCREEN_%1” [CR]
Input is Computer
“NORMAL” ---------------------- Select Normal mode
“FULL” --------------------------- Select Full screen mode
“WIDE” --------------------------- Select Wide(16:9) mode
“ZOOM” -------------------------- Select Zoom mode
“TRUE” -------------------------- Select True mode
“CUSTOM” ---------------------- Select Custom mode
“DZOOM_UP” ----------------- Scale up with Digital zoom
“DZOOM_DN” ---------------- Scale down with Digital zoom
“UP” ----- The same operation as pressing Up key or Left key
“DN” -----The same operation as pressing Down key or Right
key
Input is Video
“NORMAL” ---------------------- Select Normal mode
“FULL” --------------------------- Select Full screen mode
“WIDE” --------------------------- Select Wide(16:9) mode
“ZOOM” -------------------------- Select Zoom mode
“NATURAL” --------------------- Select Natural wide mode
“CUSTOM” ---------------------- Select Custom mode
“UP” ----- The same operation as pressing Up key or Left key
“DN” -----The same operation as pressing Down key or Right
key
%1
Common in AV/PC
“RST” ---------------------- Reset Screen adjustment
Details
Select screen size (Available only in the normal Power ON status)
When selected input does not include specified %1, error code “101” [CR] is
returned and it is not executed.
Receiving “DZOOM_UP” or “DZOOM_DN” command immediately executes the
function.
Acceptable “000” [CR]
Response
Unacceptable
“Error Code” [CR]
8.7.2 CF_DZCENT Command
Command
“CF_DZCENT_%1” [CR]
%1 “CENT” --------------- Cancel Digital Zoom (CENT: “CENTER”)
Details
Cancel Digital Zoom (Available only in the normal Power ON status and Input
for Computer is selected)
Release the image setting in case the image is enlarged or reduced.
Acceptable “000” [CR]
Response
Unacceptable
“101” [CR] ----------------- When input is Video
To Next Page
