PLC-HP7000L Expand Serial Command Functional Specifications
75/94
9.8 Screen Status Read Command
9.8.1 CR_SCREEN Command
Command “CR_SCREEN” [CR]
Details Get selected screen image size
Acceptable “000_%1” [CR]
%1
“NORMAL” ---------------------- Normal mode
“FULL” --------------------------- Full screen mode
“WIDE” --------------------------- Wide(16:9) mode
“TRUE” --------------------------- True mode
“ZOOM” --------------------------- Zoom mode
“NATURAL” ---------------------- Natural mode
“CUSTOM” ----------------------- Custom mode
Response
Unacceptable
“Error Code” [CR] --- When command is not available in the
given condition (such as being selected input).
“?” [CR] --- When unknown command is received
9.8.2 CR_VSCALE Command
Command “CR_VSCALE” [CR]
Details Get setting status of V scale
Acceptable “000_%1” [CR]
%1 “-32”-”035”
Response
Unacceptable
“Error Code” [CR]
9.8.3 CR_VPOS Command
Command “CR_VPOS” [CR]
Details Get setting status of V Position
Acceptable “000_%1” [CR]
%1 “-15”-”015”
Response
Unacceptable
“Error Code” [CR]
9.8.4 CR_HSCALE Command
Command “CR_HSCALE” [CR]
Details Get setting status of H scale
Acceptable “000_%1” [CR]
%1 “-32”-”035”
Response
Unacceptable
“Error Code” [CR]
9.8.5 CR_HPOS Command
Command “CR_HPOS” [CR]
Details Get setting status of H Position
Acceptable “000_%1” [CR]
%1 “-15”-”015”
Response
Unacceptable
“Error Code” [CR]
