PLC-HP7000L Expand Serial Command Functional Specifications
44/94
(Valid only when in the normal Power ON status.)
*When “Picture in Picture” is set to Off, return “101” [CR]
Acceptable “000” [CR]
Response
Unacceptable “Error Code” [CR]
8.9.13 CF_PIPPOSITION Command
Command “CF_PIPPOSITION_%1” [CR]
%1
“POS1” -------------------- Move main picture position to up
“POS2” -------------------- Move main picture position to down
“POS3” -------------------- Move main picture position to left
“POS4” -------------------- Move main picture position to right
“POS5” -------------------- Move sub picture position to up
“POS6” -------------------- Move sub picture position to down
“POS7” -------------------- Move sub picture position to left
“POS8” -------------------- Move sub picture position to right
Details
Set position of “Picture in Picture”.
(Valid only when in the normal Power ON status.)
This function is worked from the first reception of Command.
* When setting beyond the area of movement is carried out, return Error Code
“101” [CR] and the command is not executed.
Ex.) When movement to right side has already reached limit; and "RIGHT" is
received.
*When “Picture in Picture” is set to Off, return “101” [CR]
Acceptable “000” [CR]
Response
Unacceptable “Error Code” [CR]
8.9.14 CF_PIPFRAMELOCK Command
Command “CF_PIPFRAMELOCK_%1” [CR]
%1
“MAIN” -------------------- Set to main picture
“SUB” --------------------- Set to sub picture
Details
Set Frame lock of “Picture in Picture”.
(Valid only when in the normal Power ON status.)
Acceptable “000” [CR]
Response
Unacceptable “Error Code” [CR]
8.9.15 CF_PIPSTORE Command
Command “CF_PIPSTORE_%1” [CR]
%1
“USER1”---- Store current setting status to User 1
“USER2”---- Store current setting status to User 2
“USER3”---- Store current setting status to User 3
“USER4”---- Store current setting status to User 4
“USER5”---- Store current setting status to User 5
Details
Store setting status of “Picture in Picture”.
(Valid only when in the normal Power ON status.)
This command operates the same way as storing to User1-5 in “Picture in Picture”
Menu.
The status set by this command is stored in EEPROM and the setting remains
even after the power is turned to ALL OFF status.
Acceptable “000” [CR]
Response
Unacceptable “Error Code” [CR]
