PLC-HP7000L Expand Serial Command Functional Specifications
41/94
8.9.4 CF_INPUTBUTTON Command
Command
“CF_INPUTBUTTON_%1” [CR]
%1
“MODE1” ------------------------- Set Input button operation to MODE1
“MODE2” ------------------------- Set Input button operation to MODE2
“MODE3” ------------------------- Set Input button operation to MODE3
Details
Set Input button operation mode. (Available in normal Power ON status only).
The status set by this command is stored in EEPROM and its setting is effective
after ALL is OFF
Acceptable “000” [CR]
Response
Unacceptable
“Error Code” [CR]
8.9.5 CF_DISP Command
Command
“CF_DISP_%1” [CR]
%1
“ON” -------------------- Set Display to On
“CNTDWNOFF” ----- Set Display to Count down Off
“OFF” ------------------ Set Display to Off
“UP” -------------------- The same operation as pressing Up key or Left key
“DN” ---------------------The same operation as pressing Down key or Right key
Details
Set Display mode.(Available only in the normal Power ON status)
The value set by this command is stored in EEPROM and setting remains effective
even after the power is turned to ALL OFF status.
Acceptable “000” [CR]
Response
Unacceptable
“Error Code” [CR]
8.9.6 CF_BACKGND Command
Command
“CF_BACKGND_%1” [CR]
%1
“BLUE” -------------------- Select Blue Back
“USER” ------------------- Select User
“BLACK” ------------------ Select Black Back
“UP” ----------------------- The same operation as pressing Up key or Left key
“DN” ------------------------The same operation as pressing Down key or Right key
Details
Set Screen status for no signal. (Available only in the normal Power ON status)
The status set by this command is stored in EEPROM and the setting remains
even after the power is turned to ALL OFF status.
*When ％1=”USER” is received, error code “101” is returned, in the case of
Capture non-practice.
Acceptable “000” [CR]
Response
Unacceptable
“Error Code” [CR]
To Next Page
