Sanyo PLC-HP7000L Technical Specifications

PLC-HP7000L Expand Serial Command Functional Specifications
64/94
9.5 PC Adjust Status Read Command
9.5.1 CR_FSYNC Command
Command “CR_FSYNC” [CR]
Details Get value of Fine Sync
Acceptable “000_%1” [CR]
%1 “0000 – 0031”
Response
Unacceptable
“Error Code” [CR] --- When command is not available in the given
condition (such as being selected input)
“?” [CR] --- When unknown command is received
9.5.2 CR_TDOTS Command
Command “CR_TDOTS” [CR]
Details Get value of Total Dots
Acceptable “000_%1” [CR]
%1
“mmmm” – “nnnn”
(mmmm = Display area H + Position H)
(nnnn = Maximum value less than 140 MHz of Dot Clock)
Response
Unacceptable
“Error Code” [CR] ------------------------ When command is not
available in the given condition (such as being selected input
“?” [CR] ------------------- When unknown command is received
9.5.3 CR_CLPPHASE Command
Command “CR_CLPPHASE” [CR]
Details Get value of Clamp Phase value
Acceptable “000_%1” [CR]
%1 “0000 – 0255”
Response
Unacceptable “Error Code” [CR]
9.5.4 CR_H-POS Command
Command “CR_H-POS” [CR]
Details Get value of Horizontal Position
Acceptable “000_%1” [CR]
%1
“0000 – nnnn”
(nnnn = Total Dots – Display area H)
Response
Unacceptable
“Error Code” [CR] ------ When command is not available in the
given condition (such as being selected input
“?” [CR] ------------------- When unknown command is received
9.5.5 CR_V-POS Command
Command “CR_V-POS” [CR]
Details Get value of Vertical Position
Acceptable “000_%1” [CR]
%1
“0000 – nnnn”
(nnnn = Total Line – Display area V)
Response
Unacceptable
“Error Code” [CR] ------ When command is not available in the
given condition (such as being selected input
“?” [CR] --------------------- When unknown command is received

Sanyo PLC-HP7000L Specifications

General

Brand	Sanyo
Model	PLC-HP7000L
Category	Projector
Language	English
