PLC-HP7000L Expand Serial Command Functional Specifications
42/94
8.9.7 CF_LOGO Command
Command “CF_LOGO_%1_%2” [CR]
%1 “0000 – 9999” ------------- Directly set Logo PIN code
%2
“OFF” ---------------------------Cancel Logo display
“DFLT” ------------------------- Select Logo of Factory Default
“USER” ------------------------ Select User
“UP” ---------- The same operation as pressing Up key or Left key
“DN” ----------The same operation as pressing Down key or Right key
Details
Set Logo mode.(Available only in the normal Power ON status)
The status set by this command is stored in EEPROM and setting remains
effective even after the power is turned to ALL OFF status.
Set Logo PIN code in %1.
When Logo Lock is enabled:
PIN code is matched ------------------------- Command is valid (Acceptable)
PIN code is mismatched-------------------- Command is invalid (Error code “102”)
PIN code is beyond %1 available range -------Command is invalid (Error code”?”)
When Logo Lock is disabled:
PIN code is within %1 available range ------- Command is valid (Acceptable)
PIN code is out of %1 available range ------- Command is invalid (Error code “?”)
Note: When Logo Lock is enabled, matching Logo PIN code switches Logo but
Logo Lock is not cancelled (Lock status is kept).
*When ％2=”USER” is received, error code “101” is returned, in the case of
Capture non-practice.
Acceptable “000” [CR]
Response
Unacceptable “Error Code” [CR]
8.9.8 CF_PIP Command
Command “CF_PIP_%1” [CR]
%1
“OFF” -------------------- Select Off
“USER1” ---------------- Select User1
“USER2” ---------------- Select User2
“USER3” ---------------- Select User3
“USER4” ---------------- Select User4
“USER5” ---------------- Select User5
Details
Set ”Picture in Picture” status.(Available only in the normal Power ON status)
The status set by this command is stored in EEPROM and the setting remains
even after the power is turned to ALL OFF status.
Acceptable “000” [CR]
Response
Unacceptable “Error Code” [CR]
8.9.9 CF_PIPMODE Command
Command “CF_PIPMODE_%1” [CR]
%1
“PINP” -------------------- Select P in P mode
“PBYP” ------------------- Select P by P mode
Details Set mode in “Picture in Picture”. (Available only in the normal Power ON status)
Acceptable “000” [CR]
Response
Unacceptable “Error Code” [CR]
