SATO HR2 Series User Manual

Section 3: Operation and Configuration
Page 3-40 HR2 Series Operator Manual
3.13 TEST PRINT MODE (Cont’d)
2)Second page --
3)Third page --
Item name (Print) Item name Description
PCB Rev. CONT PCB’s ver-
sion
x.x
DSW Dip switch setting ON/OFF
Item name (Print) Item name Description
Model Name Model Name Printing the printer's model name.
FROM1 CHECK SUM Firmware’s check-
sum
Printing the checksum value in firmware area and
CODE39 barcode.
(A) xxxx (B) xxxx
(P) xxxx (E) xxxx
(K) xxxx
Checksum value differs depending on firmware version.
LAN MAC Address LAN MAC Address xx:xx:xx:xx:xx:xx
Pitch
Offset
Backfeed
Print start position
Print stop position
Backfeed amount
Printing pitch position, offset position and backfeed value
for each sensor type.
+xx(dot)
+xx(dot)
+xx(dot)
Label Size Label Size Printing the label size set in the printer.
(P)xxxx x (W)xxxx(dot)
TearOff Offset Tear Off Pitch Printing the offset for the first label in Tear off operation.
+x.xx(mm)
Item name (Print) Item name Description
Model Name Model Name Printing the printer's model name.
Life Counter Life Counter Printing the total usage.
xxxxx.x(km)
Head dot density Model
12 dot/mm HR212
24 dot/mm HR224
Head dot density Model
12 dot/mm HR212
24 dot/mm HR224
