Date _______________
Group______________
Date Code 20081022 Instruction Manual SEL-787 Relay
SET.35
of 68
SEL-787 Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
Enable IEC 61850 Protocol (Y, N) (Hidden if 61850 not supported) E61850 :=
Enable IEC 61850 GSE (Y, N)
(Hidden if E61850 := N) EGSE :=
DNP3 Protocol
All DNP3 settings below are hidden if DNP3 is not an option.
Enable DNP3 Sessions (0–3)
(DNP3 settings below
hidden if EDNP := 0) EDNP :=
DNP TCP and UDP Port (1–65534)
DNPNUM :=
DNP Address (0–65519)
DNPADR :=
Session 1
IP Address [zzz.yyy.xxx.www] (15 characters) DNPIP1 :=
Transport Protocol (UDP, TCP)
DNPTR1 :=
UDP Response Port (REQ, 1–65534)
DNPUDP1 :=
DNP Address to Report to (0–65519)
REPADR1 :=
DNP Map (1–3)
DNPMAP1 :=
Analog Input Default Variation (1–6)
DVARAI1 :=
Class for Binary Event Data (0–3)
ECLASSB1 :=
Class for Counter Event Data (0–3)
ECLASSC1 :=
Class for Analog Event Data (0–3)
ECLASSA1 :=
Currents Scaling Decimal Places (0–3)
DECPLA1 :=
Voltages Scaling Decimal Places (0–3)
DECPLV1 :=
Misc Data Scaling Decimal Places (0–3)
DECPLM1 :=
Amps Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA1 := 0)
ANADBA1 :=
Volts Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA1 := 0)
ANADBV1 :=
Misc Data Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA1 := 0 and ECLASSC1 := 0)
ANADBM1 :=
Minutes for Request Interval (I, M, 1–32767)
TIMERQ1 :=
Seconds to Select/Operate Time-Out (0.0–30.0)
STIMEO1 :=
Seconds to send Data Link Heartbeat (0–7200)
(Hidden if DNPTR1 := UDP)
DNPINA1 :=
Event Message Confirm Time-Out (1–50 sec))
ETIMEO1 :=
Enable Unsolicited Reporting (Y, N)
(Hidden if ECLASSA1 := 0, ECLASSB1 := 0, ECLASSC1 := 0, and
ECLASSV1 := 0)
UNSOL1 :=
Enable Unsolicited Reporting at Power-Up (Y, N)
(Hidden if UNSOL1 := N)
PUNSOL1 :=
Number of Events to Transmit On (1–200)
(Hidden if UNSOL1 := N)
NUMEVE1 :=
Oldest Event to Tx On (0.0–99999.0 sec)
(Hidden if UNSOL1 := N)
AGEEVE1 :=
To Next Page
