SEL-787 Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
SEL-787 Relay Instruction Manual Date Code 20081022
Date _______________
Group______________
SET PORT p (p = F, 1, 2, 3, or 4) Command
PORT F
PROTOCOL (SEL, MOD, EVMSG, PMU) PROTO :=
Communications
SPEED (300, 1200, 2400, 4800, 9600, 19200, 38400 bps) SPEED :=
DATA BITS (7, 8 bits)
(Hidden if PROTO := MOD, EVMSG, or
PMU)
BITS :=
PARITY (O, E, N)
(Hidden if PROTO := EVMSG or PMU) PARITY :=
STOP BITS (1, 2 bits)
(Hidden if PROTO := MOD or EVMSG) STOP :=
PORT TIME-OUT (0–30 min)
(Hidden if PROTO := MOD,
EVMSG or PMU)
T_OUT :=
SEND AUTOMESSAGE (Y, N)
(Hidden if PROTO := MOD,
EVMSG, or PMU)
AUTO :=
HDWR HANDSHAKING (Y, N)
(Hidden if PROTO := MOD or
EVMSG)
RTSCTS :=
Modbus Protocol
MODBUS SLAVE ID (1–247) (Hidden if PROTO := SEL,
EVMSG, or PMU)
SLAVEID :=
PORT 1 (Ethernet Port in Slot B)
All Ethernet settings are hidden if an Ethernet option is not available.
IP ADDRESS (zzz.yyy.xxx.www)
IPADDR :=
SUBNET MASK (zzz.yyy.xxx.www)
SUBNETM :=
DEFAULT ROUTER (zzz.yyy.xxx.www)
DEFRTR :=
Enable TCP Keep-Alive (Y, N)
ETCPKA :=
TCP Keep-Alive Idle Range (1–20 sec)
(Hidden if ETCPKA := N) KAIDLE :=
TCP Keep-Alive Interval Range (1–20 sec)
(Hidden if ETCPKA := N)
KAINTV :=
TCP Keep-Alive Count Range (1–20 sec)
(Hidden if ETCPKA := N)
KACNT :=
OPERATING MODE (Fixed, Failover, Switched)
(Hidden if not dual redundant Ethernet Port option)
NETMODE :=
FAILOVER TIMEOUT (0.10–65.00 sec)
(Hidden if not dual redundant Ethernet Port option or if NETMODE
is not FAILOVER)
FTIME :=
PRIMARY NET PORT (A, B, D)
(Hidden if not dual redundant Ethernet Port option)
NETPORT :=
NETWRK PORTA SPD (Auto, 10, 100 Mbps)
NETASPD :=
NETWRK PORTB SPD (Auto, 10, 100 Mbps)
(Hidden if not dual redundant Ethernet Port option)
NETBSPD :=
TELNET PORT (23, 1025–65534)
TPORT :=
TELNET TIME-OUT (1–30 min)
TIDLE :=
FTP USER NAME (20 characters)
FTPUSER :=
