SEL-787 Settings Sheets
Global Settings (SET G Command)
Input Debounce Settings (Slot E)
IN501 Debounce (AC, 0–65000 ms) IN501D :=
IN502 Debounce (AC, 0–65000 ms)
IN502D :=
IN503 Debounce (AC, 0–65000 ms)
IN503D :=
IN504 Debounce (AC, 0–65000 ms)
IN504D :=
IN505 Debounce (AC, 0–65000 ms)
IN505D :=
IN506 Debounce (AC, 0–65000 ms)
IN506D :=
IN507 Debounce (AC, 0–65000 ms)
IN507D :=
IN508 Debounce (AC, 0–65000 ms)
IN508D :=
Data Reset
RESET TARGETS (SELOGIC) RSTTRGT :=
RESET ENERGY (SEL
OGIC) RSTENRGY:=
RESET MAX/MIN (SEL
OGIC) RSTMXMN:=
RESET DEMAND ((SEL
OGIC) RSTDEM :=
RESET PK DEMAND ((SEL
OGIC) RSTPKDEM:=
Access Control
DISABLE SETTINGS (SELOGIC) DSABLSET :=
