D.22
SEL-787 Relay Instruction Manual Date Code 20081022
DNP3 Communications
DNP3 Documentation
30 4
e
16-Bit Analog Input Without Flag 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 5 Short Floating Point Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 6 Long Floating Point Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
31 0 Frozen Analog Input—All Variations
31 1 32-Bit Frozen Analog Input
31 2 16-Bit Frozen Analog Input
31 3 32-Bit Frozen Analog Input With Time of
Freeze
31 4 16-Bit Frozen Analog Input With Time of
Freeze
31 5 32-Bit Frozen Analog Input Without Flag
31 6 16-Bit Frozen Analog Input Without Flag
31 7 Short Floating Point Frozen Analog Input
31 8 Long Floating Point Frozen Analog Input
32 0 Analog Change Event—All Variations 1 6, 7, 8
32 1 32-Bit Analog Change Event Without Time 1 6, 7, 8 129 17, 28
32 2
e
16-Bit Analog Change Event Without Time 1 6, 7, 8 129, 130 17, 28
32 3 32-Bit Analog Change Event With Time 1 6, 7, 8 129 17, 28
32 4 16-Bit Analog Change Event With Time 1 6, 7, 8 129 17, 28
32 5 Short Floating Point Analog Change Event 1 6, 7, 8 129 17, 28
32 6 Long Floating Point Analog Change Event 1 6, 7, 8 129 17, 28
32 7 Short Floating Point Analog Change Event
With Time
1 6, 7, 8 129 17, 28
32 8 Long Floating Point Analog Change Event
With Time
1 6, 7, 8 129 17, 28
33 0 Frozen Analog Event—All Variations
33 1 32-Bit Frozen Analog Event Without Time
33 2 16-Bit Frozen Analog Event Without Time
33 3 32-Bit Frozen Analog Event With Time
33 4 16-Bit Frozen Analog Event With Time
33 5 Short Floating Point Frozen Analog Event
33 6 Long Floating Point Frozen Analog Event
33 7 Short Floating Point Frozen Analog Event
With Time
33 8 Long Floating Point Frozen Analog Event
With Time
34 0 Analog Deadband—All Variations
34 1
e
16-Bit Analog Input Reporting Deadband
Object
1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
34 2 32-Bit Analog Input Reporting Deadband
Object
1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
34 3 Floating Point Analog Input Reporting
Deadband Object
1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
Ta b l e D.1 1 S E L - 787 DN P Ob je ct L ist (Sheet 3 of 5)
Obj. Var. Description
Request
a
Response
b
Funct. Codes
c
Qual. Codes
d
Funct. Codes
c
Qual. Codes
d
