D.23
Date Code 20081022 Instruction Manual SEL-787 Relay
DNP3 Communications
DNP3 Documentation
40 0 Analog Output Status—All Variations 1 0, 1, 6, 7, 8 129
40 1 32-Bit Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 2
e
16-Bit Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 3 Short Floating Point Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 4 Long Floating Point Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
41 0 Analog Output Block—All Variations
41 1 32-Bit Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
41 2
e
16-Bit Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
41 3 Short Floating Point Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
50 0 Time and Date—All Variations
50 1 Time and Date 1, 2 7, 8 index=0 129 07, quantity=1
50 2 Time and Date With Interval
50 3 Time and Date Last Recorded 2 7, 8
51 0 Time and Date CTO—All Variations
51 1 Time and Date CTO
51 2 Unsynchronized Time and Date CTO 129 07, quantity=1
52 0 Time Delay—All Variations
52 1 Time Delay, Coarse
52 2 Time Delay, Fine 129 7, quantity=1
60 0 All Classes of Data 1, 20, 21 6, 7, 8
60 1 Class 0 Data 1, 20, 21 6, 7, 8
60 2 Class 1 Data 1 6, 7, 8
60 3 Class 2 Data 1, 20, 21 6, 7, 8
60 4 Class 3 Data 1, 20, 21 6, 7, 8
70 1 File Identifier
70 2 Authentication Object
70 3 File Command Object
70 4 File Command Status Object
70 5 File Transport Object
70 6 File Transport Status Object
70 7 File Descriptor Object
80 1 Internal Indications 2 0, 1 index=7
81 1 Storage Object
82 1 Device Profile
83 1 Private Registration Object
83 2 Private Registration Object Descriptor
90 1 Application Identifier
100 1 Short Floating Point
100 2 Long Floating Point
100 3 Extended Floating Point
Ta b l e D.1 1 S E L - 787 DN P Ob je ct L ist (Sheet 4 of 5)
Obj. Var. Description
Request
a
Response
b
Funct. Codes
c
Qual. Codes
d
Funct. Codes
c
Qual. Codes
d
