Winding 1 Maximum Phase Instantaneous Overcurrent (WDG1 Max Ph IOC)
324 (R/W) WDG1 IOC L1 EN 0 1 0 424
0=N
1=Y
325 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 425
326 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 426
327 (R/W) WDG1 IOC L2 EN 0 1 0 427
0=N
1=Y
328 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 428
329 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 429
330 (R/W) WDG1 IOC L3 EN 0 1 0 430
0=N
1=Y
331 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 431
332 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 432
333 (R/W) WDG1 IOC L4 EN 0 1 0 433
0=N
1=Y
334 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 434
335 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 435
Winding 1 Residual Instantaneous Overcurrent (WDG1 Res IOC)
336 (R/W) WDG1 RESIOC L1EN 0 1 0 436
0=N
1=Y
337 (R/W) RES IOC LEVEL A 10 9600 200 0.01 437
338 (R/W) RES IOC DELAY sec 0 500 50 0.01 438
339 (R/W) WDG1 RESIOC L2EN 0 1 0 439
0=N
1=Y
340 (R/W) RES IOC LEVEL A 10 9600 200 0.01 440
341 (R/W) RES IOC DELAY sec 0 500 50 0.01 441
Winding 1 Negative-Sequence Instantaneous Overcurrent (WDG1 Neg Seq IOC)
342 (R/W) W1 NSEQ IOC L1EN 0 1 0 442
0=N
1=Y
343 (R/W) NSEQ IOC LEVEL A 10 9600 200 0.01 443
344 (R/W) NSEQ IOC DELAY sec 1 1200 2 0.1 444
345 (R/W) W1 NSEQ IOC L2EN 0 1 0 445
0=N
1=Y
346 (R/W) NSEQ IOC LEVEL A 10 9600 200 0.01 446
347 (R/W) NSEQ IOC DELAY sec 1 1200 2 0.1 447
Table E.32 Modbus Register Map
a
(Sheet 4 of 38)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fa c tor
DeviceNet
Parameter
Numbers
