E.27
Date Code 20081022 Instruction Manual SEL-787 Relay
Modbus RTU Communications
Modbus Register Map
364 (R/W) NSEQ TOC CURVE 0 9 2 464
0=U1
1=U2
2=U3
3=U4
4=U5
5=C1
6=C2
7=C3
8=C4
9=C5
365 (R/W) NSEQ TOC TDIAL 5 1500 300 0.01 465
366 (R/W) EM RESET DELAY 0 1 0 466
0=N
1=Y
367 (R/W) CONST TIME ADDER sec 0 100 0 0.01 467
368 (R/W) MIN RESPONSE TIM sec 0 100 0 0.01 468
Winding 2 Maximum Phase Instantaneous Overcurrent (WDG2 Max Ph IOC)
369 (R/W) WDG2 IOC L1 EN 0 1 0 469
0=N
1=Y
370 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 470
371 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 471
372 (R/W) WDG2 IOC L2 EN 0 1 0 472
0=N
1=Y
373 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 473
374 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 474
375 (R/W) WDG2 IOC L3 EN 0 1 0 475
0=N
1=Y
376 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 476
377 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 477
378 (R/W) WDG2 IOC L4 EN 0 1 0 478
0=N
1=Y
379 (R/W) PHASE IOC LEVEL A 10 9600 200 0.01 479
380 (R/W) PHASE IOC DELAY sec 0 500 0 0.01 480
Winding 2 Residual Instantaneous Overcurrent (WDG2 Res IOC)
381 (R/W) WDG2 RESIOC L1EN 0 1 0 481
0=N
1=Y
382 (R/W) RES IOC LEVEL A 10 9600 200 0.01 482
383 (R/W) RES IOC DELAY sec 0 500 50 0.01 483
384 (R/W) WDG2 RESIOC L2EN 0 1 0 484
0=N
1=Y
385 (R/W) RES IOC LEVEL A 10 9600 200 0.01 485
386 (R/W) RES IOC DELAY sec 0 500 50 0.01 486
Table E.32 Modbus Register Map
a
(Sheet 6 of 38)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fa c tor
DeviceNet
Parameter
Numbers
