Schweitzer Engineering Laboratories SEL-787 - Page 445

E.31
Date Code 20081022 Instruction Manual SEL-787 Relay
Modbus RTU Communications
Modbus Register Map
441 (R/W) RTD3 LOCATION 0 2 0 541
0=OFF
1=AMB
2=OTH
442 (R/W) RTD3 TYPE 0 3 0 542
0 = PT100
1 = NI100
2 = NI120
3=CU10
443 (R/W) RTD3 TRIP LEVEL degC 0 250 0 1 543
0=Off
444 (R/W) RTD3 WARN LEVEL degC 0 250 0 1 544
0=Off
445 (R/W) RTD4 LOCATION 0 2 0 545
0=OFF
1=AMB
2=OTH
446 (R/W) RTD4 TYPE 0 3 0 546
0 = PT100
1 = NI100
2 = NI120
3=CU10
447 (R/W) RTD4 TRIP LEVEL degC 0 250 0 1 547
0=Off
448 (R/W) RTD4 WARN LEVEL degC 0 250 0 1 548
0=Off
449 (R/W) RTD5 LOCATION 0 2 0 549
0=OFF
1=AMB
2=OTH
450 (R/W) RTD5 TYPE 0 3 0 550
0 = PT100
1 = NI100
2 = NI120
3=CU10
451 (R/W) RTD5 TRIP LEVEL degC 0 250 0 1 551
0=Off
452 (R/W) RTD5 WARN LEVEL degC 0 250 0 1 552
0=Off
453 (R/W) RTD6 LOCATION 0 2 0 553
0=OFF
1=AMB
2=OTH
454 (R/W) RTD6 TYPE 0 3 0 554
0 = PT100
1 = NI100
2 = NI120
3=CU10
455 (R/W) RTD6 TRIP LEVEL degC 0 250 0 1 555
0=Off
456 (R/W) RTD6 WARN LEVEL degC 0 250 0 1 556
0=Off
Table E.32 Modbus Register Map
a
(Sheet 10 of 38)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fa c tor
DeviceNet
Parameter
Numbers
