E.32
SEL-787 Relay Instruction Manual Date Code 20081022
Modbus RTU Communications
Modbus Register Map
457 (R/W) RTD7 LOCATION 0 2 0 557
0=OFF
1=AMB
2=OTH
458 (R/W) RTD7 TYPE 0 3 0 558
0 = PT100
1 = NI100
2 = NI120
3=CU10
459 (R/W) RTD7 TRIP LEVEL degC 0 250 0 1 559
0=Off
460 (R/W) RTD7 WARN LEVEL degC 0 250 0 1 560
0=Off
461 (R/W) RTD8 LOCATION 0 2 0 561
0=OFF
1=AMB
2=OTH
462 (R/W) RTD8 TYPE 0 3 0 562
0 = PT100
1 = NI100
2 = NI120
3=CU10
463 (R/W) RTD8 TRIP LEVEL degC 0 250 0 1 563
0=Off
464 (R/W) RTD8 WARN LEVEL degC 0 250 0 1 564
0=Off
465 (R/W) RTD9 LOCATION 0 2 0 565
0=OFF
1=AMB
2=OTH
466 (R/W) RTD9 TYPE 0 3 0 566
0 = PT100
1 = NI100
2 = NI120
3=CU10
467 (R/W) RTD9 TRIP LEVEL degC 0 250 0 1 567
0=Off
468 (R/W) RTD9 WARN LEVEL degC 0 250 0 1 568
0=Off
469 (R/W) RTD10 LOCATION 0 2 0 569
0=OFF
1=AMB
2=OTH
470 (R/W) RTD10 TYPE 0 3 0 570
0 = PT100
1 = NI100
2 = NI120
3=CU10
471 (R/W) RTD10 TRIP LEVEL degC 0 250 0 1 571
0=Off
472 (R/W) RTD10 WARN LEVEL degC 0 250 0 1 572
0=Off
Table E.32 Modbus Register Map
a
(Sheet 11 of 38)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fa c tor
DeviceNet
Parameter
Numbers
