E.43
Date Code 20081022 Instruction Manual SEL-787 Relay
Modbus RTU Communications
Modbus Register Map
860 (R) RTD5 MAX degC -32768 32767 0 1 960
861 (R) RTD5 MIN degC -32768 32767 0 1 961
862 (R) RTD6 MAX degC -32768 32767 0 1 962
863 (R) RTD6 MIN degC -32768 32767 0 1 963
864 (R) RTD7 MAX degC -32768 32767 0 1 964
865 (R) RTD7 MIN degC -32768 32767 0 1 965
866 (R) RTD8 MAX degC -32768 32767 0 1 966
867 (R) RTD8 MIN degC -32768 32767 0 1 967
868 (R) RTD9 MAX degC -32768 32767 0 1 968
869 (R) RTD9 MIN degC -32768 32767 0 1 969
870 (R) RTD10 MAX degC -32768 32767 0 1 970
871 (R) RTD10 MIN degC -32768 32767 0 1 971
872 (R) RTD11 MAX degC -32768 32767 0 1 972
873 (R) RTD11 MIN degC -32768 32767 0 1 973
874 (R) RTD12 MAX degC -32768 32767 0 1 974
875 (R) RTD12 MIN degC -32768 32767 0 1 975
MAX/MIN AI3 Data
876 (R) AI301 MX–HI EU -32768 32767 0 0.001 976
877 (R) AI301 MX–LO EU -32768 32767 0 0.001 977
878 (R) AI301 MN–HI EU -32768 32767 0 0.001 978
879 (R) AI301 MN–LO EU -32768 32767 0 0.001 979
880 (R) AI302 MX–HI EU -32768 32767 0 0.001 980
881 (R) AI302 MX–LO EU -32768 32767 0 0.001 981
882 (R) AI302 MN–HI EU -32768 32767 0 0.001 982
883 (R) AI302 MN–LO EU -32768 32767 0 0.001 983
884 (R) AI303 MX–HI EU -32768 32767 0 0.001 984
885 (R) AI303 MX–LO EU -32768 32767 0 0.001 985
886 (R) AI303 MN–HI EU -32768 32767 0 0.001 986
887 (R) AI303 MN–LO EU -32768 32767 0 0.001 987
888 (R) AI304 MX–HI EU -32768 32767 0 0.001 988
889 (R) AI304 MX–LO EU -32768 32767 0 0.001 989
890 (R) AI304 MN–HI EU -32768 32767 0 0.001 990
891 (R) AI304 MN–LO EU -32768 32767 0 0.001 991
MAX/MIN AI4 Data
892 (R) AI401 MX–HI EU -32768 32767 0 0.001 992
893 (R) AI401 MX–LO EU -32768 32767 0 0.001 993
894 (R) AI401 MN–HI EU -32768 32767 0 0.001 994
895 (R) AI401 MN–LO EU -32768 32767 0 0.001 995
896 (R) AI402 MX–HI EU -32768 32767 0 0.001 996
897 (R) AI402 MX–LO EU -32768 32767 0 0.001 997
898 (R) AI402 MN–HI EU -32768 32767 0 0.001 998
899 (R) AI402 MN–LO EU -32768 32767 0 0.001 999
Table E.32 Modbus Register Map
a
(Sheet 22 of 38)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fa c tor
DeviceNet
Parameter
Numbers
