E.45
Date Code 20081022 Instruction Manual SEL-787 Relay
Modbus RTU Communications
Modbus Register Map
948 (R) AI401–HI EU -32768 32767 0 0.001 1048
949 (R) AI401–LO EU -32768 32767 0 0.001 1049
950 (R) AI402–HI EU -32768 32767 0 0.001 1050
951 (R) AI402–LO EU -32768 32767 0 0.001 1051
952 (R) AI403–HI EU -32768 32767 0 0.001 1052
953 (R) AI403–LO EU -32768 32767 0 0.001 1053
954 (R) AI404–HI EU -32768 32767 0 0.001 1054
955 (R) AI404–LO EU -32768 32767 0 0.001 1055
956 (R) AI501–HI EU -32768 32767 0 0.001 1056
957 (R) AI501–LO EU -32768 32767 0 0.001 1057
958 (R) AI502–HI EU -32768 32767 0 0.001 1058
959 (R) AI502–LO EU -32768 32767 0 0.001 1059
960 (R) AI503–HI EU -32768 32767 0 0.001 1060
961 (R) AI503–LO EU -32768 32767 0 0.001 1061
962 (R) AI504–HI EU -32768 32767 0 0.001 1062
963 (R) AI504–LO EU -32768 32767 0 0.001 1063
964–969 (R) Reserved
c
0 0 0 1064–1069
Math Variables
970 (R) MV01–HI -32768 32767 0 0.01 1070
971 (R) MV01–LO -32768 32767 0 0.01 1071
972 (R) MV02–HI -32768 32767 0 0.01 1072
973 (R) MV02–LO -32768 32767 0 0.01 1073
974 (R) MV03–HI -32768 32767 0 0.01 1074
975 (R) MV03–LO -32768 32767 0 0.01 1075
976 (R) MV04–HI -32768 32767 0 0.01 1076
977 (R) MV04–LO -32768 32767 0 0.01 1077
978 (R) MV05–HI -32768 32767 0 0.01 1078
979 (R) MV05–LO -32768 32767 0 0.01 1079
980 (R) MV06–HI -32768 32767 0 0.01 1080
981 (R) MV06–LO -32768 32767 0 0.01 1081
982 (R) MV07–HI -32768 32767 0 0.01 1082
983 (R) MV07–LO -32768 32767 0 0.01 1083
984 (R) MV08–HI -32768 32767 0 0.01 1084
985 (R) MV08–LO -32768 32767 0 0.01 1085
986 (R) MV09–HI -32768 32767 0 0.01 1086
987 (R) MV09–LO -32768 32767 0 0.01 1087
988 (R) MV10–HI -32768 32767 0 0.01 1088
989 (R) MV10–LO -32768 32767 0 0.01 1089
990 (R) MV11–HI -32768 32767 0 0.01 1090
991 (R) MV11–LO -32768 32767 0 0.01 1091
992 (R) MV12–HI -32768 32767 0 0.01 1092
993 (R) MV12–LO -32768 32767 0 0.01 1093
994 (R) MV13–HI -32768 32767 0 0.01 1094
995 (R) MV13–LO -32768 32767 0 0.01 1095
996 (R) MV14–HI -32768 32767 0 0.01 1096
Table E.32 Modbus Register Map
a
(Sheet 24 of 38)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fa c tor
DeviceNet
Parameter
Numbers
