E.46
SEL-787 Relay Instruction Manual Date Code 20081022
Modbus RTU Communications
Modbus Register Map
997 (R) MV14–LO -32768 32767 0 0.01 1097
998 (R) MV15–HI -32768 32767 0 0.01 1098
999 (R) MV15–LO -32768 32767 0 0.01 1099
1000 (R) MV16–HI -32768 32767 0 0.01 1100
1001 (R) MV16–LO -32768 32767 0 0.01 1101
1002 (R) MV17–HI -32768 32767 0 0.01 1102
1003 (R) MV17–LO -32768 32767 0 0.01 1103
1004 (R) MV18–HI -32768 32767 0 0.01 1104
1005 (R) MV18–LO -32768 32767 0 0.01 1105
1006 (R) MV19–HI -32768 32767 0 0.01 1106
1007 (R) MV19–LO -32768 32767 0 0.01 1107
1008 (R) MV20–HI -32768 32767 0 0.01 1108
1009 (R) MV20–LO -32768 32767 0 0.01 1109
1010 (R) MV21–HI -32768 32767 0 0.01 1110
1011 (R) MV21–LO -32768 32767 0 0.01 1111
1012 (R) MV22–HI -32768 32767 0 0.01 1112
1013 (R) MV22–LO -32768 32767 0 0.01 1113
1014 (R) MV23–HI -32768 32767 0 0.01 1114
1015 (R) MV23–LO -32768 32767 0 0.01 1115
1016 (R) MV24–HI -32768 32767 0 0.01 1116
1017 (R) MV24–LO -32768 32767 0 0.01 1117
1018 (R) MV25–HI -32768 32767 0 0.01 1118
1019 (R) MV25–LO -32768 32767 0 0.01 1119
1020 (R) MV26–HI -32768 32767 0 0.01 1120
1021 (R) MV26–LO -32768 32767 0 0.01 1121
1022 (R) MV27–HI -32768 32767 0 0.01 1122
1023 (R) MV27–LO -32768 32767 0 0.01 1123
1024 (R) MV28–HI -32768 32767 0 0.01 1124
1025 (R) MV28–LO -32768 32767 0 0.01 1125
1026 (R) MV29–HI -32768 32767 0 0.01 1126
1027 (R) MV29–LO -32768 32767 0 0.01 1127
1028 (R) MV30–HI -32768 32767 0 0.01 1128
1029 (R) MV30–LO -32768 32767 0 0.01 1129
1030 (R) MV31–HI -32768 32767 0 0.01 1130
1031 (R) MV31–LO -32768 32767 0 0.01 1131
1032 (R) MV32–HI -32768 32767 0 0.01 1132
1033 (R) MV32–LO -32768 32767 0 0.01 1133
Device Counters
1034 (R) COUNTER SC01 0 65000 0 1 1134
•
•
•
•
•
•
1065 (R) COUNTER SC32 0 65000 0 1 1165
1066–1081 (R) Reserved
c
0 0 0 1166–1181
Table E.32 Modbus Register Map
a
(Sheet 25 of 38)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fa c tor
DeviceNet
Parameter
Numbers
