E.50
SEL-787 Relay Instruction Manual Date Code 20081022
Modbus RTU Communications
Modbus Register Map
1143 (R) ROW 1 0 255 0 1243
Bit 0 = 50P24T
Bit 1 = 50P23T
Bit 2 = 50P22T
Bit 3 = 50P21T
Bit 4 = 50P14T
Bit 5 = 50P13T
Bit 6 = 50P12T
Bit 7 = 50P11T
1144 (R) ROW 2 0 255 0 1244
Bit 0 = 50Q22T
Bit 1 = 50Q21T
Bit 2 = 50G22T
Bit 3 = 50G21T
Bit 4 = 50Q12T
Bit 5 = 50Q11T
Bit 6 = 50G12T
Bit 7 = 50G11T
1145 (R) ROW 3 0 255 0 1245
Bit 0 = REF1P
Bit 1 = REF1R
Bit 2 = REF1F
Bit 3 = 50GREF1
Bit 4 = REF1E
Bit 5 = 50NREF1
Bit 6 = 50N12T
Bit 7 = 50N11T
1146 (R) ROW 4 0 255 0 1246
Bit 0 = *
Bit 1 = 51N1T
Bit 2 = 51Q2T
Bit 3 = 51Q1T
Bit 4 = 51G2T
Bit 5 = 51G1T
Bit 6 = 51P2T
Bit 7 = 51P1T
1147 (R) ROW 5 0 255 0 1247
Bit 0 = 87R
Bit 1 = 87R3
Bit 2 = 87R2
Bit 3 = 87R1
Bit 4 = 87U
Bit 5 = 87U3
Bit 6 = 87U2
Bit 7 = 87U1
1148 (R) ROW 6 0 255 0 1248
Bit 0 = 3PWR2T
Bit 1 = 3PWR1T
Bit 2 = 59P2T
Bit 3 = 59P1T
Bit 4 = 27P2T
Bit 5 = 27P1T
Bit 6 = 87AT
Bit 7 = TH5T
Table E.32 Modbus Register Map
a
(Sheet 29 of 38)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fa c tor
DeviceNet
Parameter
Numbers
