E.51
Date Code 20081022 Instruction Manual SEL-787 Relay
Modbus RTU Communications
Modbus Register Map
1149 (R) ROW 7 0 255 0 1249
Bit 0 = 59Q2T
Bit 1 = 59Q1T
Bit 2 = BFT2
Bit 3 = BFT1
Bit 4 = 81D4T
Bit 5 = 81D3T
Bit 6 = 81D2T
Bit 7 = 81D1T
1150 (R) ROW 8 0 255 0 1250
Bit 0 = RTDT
Bit 1 = *
Bit 2 = *
Bit 3 = 24CR
Bit 4 = 24C2T
Bit 5 = 24C2
Bit 6 = 24D1T
Bit 7 = 24D1
1151 (R) ROW 9 0 255 0 1251
Bit 0 = ORED51T
Bit 1 = ORED50T
Bit 2 = *
Bit 3 = *
Bit 4 = *
Bit 5 = *
Bit 6 = *
Bit 7 = REMTRIP
1152 (R) ROW 10 0 255 0 1252
Bit 0 = 50P24P
Bit 1 = 50P23P
Bit 2 = 50P22P
Bit 3 = 50P21P
Bit 4 = 50P14P
Bit 5 = 50P13P
Bit 6 = 50P12P
Bit 7 = 50P11P
1153 (R) ROW 11 0 255 0 1253
Bit 0 = 50Q22P
Bit 1 = 50Q21P
Bit 2 = 50G22P
Bit 3 = 50G21P
Bit 4 = 50Q12P
Bit 5 = 50Q11P
Bit 6 = 50G12P
Bit 7 = 50G11P
1154 (R) ROW 12 0 255 0 1254
Bit 0 = 52A2
Bit 1 = 52A1
Bit 2 = *
Bit 3 = *
Bit 4 = *
Bit 5 = *
Bit 6 = 50N12P
Bit 7 = 50N11P
Table E.32 Modbus Register Map
a
(Sheet 30 of 38)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fa c tor
DeviceNet
Parameter
Numbers
