2 SEL-787 Relay Command Summary
SEL-787 Relay Instruction Manual Date Code 20081022
EVE DIF1 n Show differential element 1 event report number n, with 1/4-cycle resolution.
EVE DIF2 n Show differential element 2 event report number n, with 1/4-cycle resolution.
EVE DIF3 n Show differential element 3 event report number n, with 1/4-cycle resolution.
EVE R n Show raw analog data event report number n, with 1/16-cycle resolution, same as EVE n R.
FIL DIR Return a list of files.
FIL READ filename Transfer settings file filename from the relay to the PC.
FIL SHOW filename Filename 1 displays contents of the file filename.
GOO k Display transmit and receive GOOSE messaging information. Enter number k to scroll the GOOSE data k
times on the screen.
GRO Display active group setting.
HEL Display a short description of selected commands.
HIS n Show summary of n latest event reports, where n = 1 is the most recent entry. If n is not specified, all event
report summaries are displayed.
HIS C or R Clear or reset history buffer.
IRIG Force synchronization of internal control clock to IRIG-B time-code input.
LDP Display signal profile data.
LDP C Clear signal profile data.
MAC Display the MAC address of the Ethernet port (PORT 1).
MET Display fundamental metering data. (Can also use MET F.)
MET k Display fundamental metering data k times, where k is between 1 and 32767.
MET AI Display analog input (transducer) data.
MET DEM k Display demand metering data, in primary amperes. Enter number k to scroll metering k times on screen.
MET DIF k Display differential metering data. Enter number k to scroll metering k times on screen.
MET E Display energy metering data.
MET H Generate harmonic report for all input currents and voltages, showing first to fifth harmonic levels and
%THD (total harmonic distortion).
MET M Display minimum and maximum metering data.
MET MV Display SEL
OGIC math variable data.
MET PEA k Display peak demand metering data, in primary amperes. Enter number k to scroll metering k times on
screen.
MET PM Display synchrophasor metering data.
MET RD Reset demand metering values.
MET RE Reset energy metering data.
MET RM Reset minimum and maximum metering data.
MET RMS Display RMS metering data.
MET RP Reset peak demand metering values.
MET T Display RTD metering data.
Serial Port Command Command Description
