3SEL-787 Relay Command Summary
Date Code 20081022 Instruction Manual SEL-787 Relay
PING x.x.x.x t Determine if Ethernet port is functioning or configured properly. x.x.x.x is the IP address and “t” is the
PING interval settable from 2 to 255 seconds. Default “t” is 1 second. Press Q to stop.
SER Display all Sequential Events Recorder (SER) data.
SER d1 Display all SER records made on date d1.
SER d1 d2 Display all SER records made from dates d2 to d1, inclusive, starting with d2.
SER n Display the n most recent SER records starting with record n.
SER n1 n2 Display SER records n2 to n1, starting with n2.
SER C or R Clear SER data.
SER D Display SER delete report, which shows deleted items (use when SER Auto Deletion is selected to
remove chatter)
SHO n Display relay group settings (n = 1, 2, 3, or 4), shows n =1 if n is not listed.
SHO DNP n Display DNP data map settings for map n (n = 1, 2, or 3).
SHO F Display front-panel settings.
SHO G Display global settings.
SHO L Display general logic settings.
SHO M Display Modbus User Map settings.
SHO P n Display port settings, where n specifies the port (1, 2, 3, 4, or F); n defaults to the active port if not listed.
SHO R Display report settings.
STA Display relay self-test status.
STA S Display SEL
OGIC usage status report.
SUM Display an event summary.
SUM R or C Reset event summary buffer.
TAR Display default target row or the most recently viewed target row.
TAR n Display target row n.
TAR n k Display target row n. Repeat display of row n for repeat count k.
TAR name Display the target row with target name in the row.
TAR name k Display the target row with target name in the row. Repeat display of this row for repeat count k.
TAR R Reset any latched targets and the most recently viewed target row.
TFE Displays cumulative and individual through-fault event data. The twenty (20) most recent individual
events are displayed.
TFE n Displays cumulative and individual through-fault event data. The n most recent individual events are
displayed, where n = 1 to 500.
TFE A Displays cumulative and individual through-fault event data. The most recent individual events are
displayed, up to 500.
TFE R or C Clears/resets cumulative and individual through-fault event data.
TFE P Preloads cumulative through-fault event data.
TIM View time.
TIM hh:mm:ss Set time by entering TIM followed by hours, minutes, and seconds, as shown (24-hour clock).
TRI Trigger an event report data capture.
Serial Port Command Command Description
