10-28 Serial Port Communications and Commands Date Code 990215
SEL-351P Manual Técnico
=>SHO <ENTER>
Group 1
Group Settings:
RID =RECLOSER R1 TID =FEEDER 2101
CTR = 200.0 CTRN = 200.0 PTR = 100.0 PTRS = 100.0
Z1MAG = 6.40 Z1ANG = 68.86
Z0MAG = 19.15 Z0ANG = 72.47 LL = 4.84
E50P = 6 E50N = 6 E50G = 6 E50Q = N
E51P = 2 E51N = 2 E51G = 2 E51Q = N
E32 = N ELOAD = N ESOTF = N EVOLT = Y
E25 = N EFLOC = N ELOP = N ECOMM = N
E81 = 6 E79 = 4 ESV = 16
EDEM = THM
50P1P = OFF 50P2P = OFF 50P3P = OFF 50P4P = OFF
50P5P = OFF 50P6P = 1.00
67P1D = 0.00 67P2D = 0.00 67P3D = 0.00 67P4D = 0.00
50PP1P= OFF 50PP2P= OFF 50PP3P= OFF 50PP4P= OFF
50N1P = OFF 50N2P = OFF 50N3P = OFF 50N4P = OFF
50N5P = OFF 50N6P = OFF
Press RETURN to continue
67N1D = 0.00 67N2D = 0.00 67N3D = 0.00 67N4D = 0.00
50G1P = OFF 50G2P = OFF 50G3P = OFF 50G4P = OFF
50G5P = OFF 50G6P = 0.25
67G1D = 0.00 67G2D = 0.00 67G3D = 0.00 67G4D = 0.00
51P1P = 1.00 51P1C = A 51P1TD= 1.00
51P1CT= 0.00 51P1MR= 0.00
51P2P = 1.00 51P2C = C 51P2TD= 1.00
51P2CT= 0.00 51P2MR= 0.00
51N1P = OFF 51N1C = 1 51N1TD= 1.00
51N1CT= 0.00 51N1MR= 0.00
51N2P = OFF 51N2C = 13 51N2TD= 1.00
51N2CT= 0.00 51N2MR= 0.00
51G1P = 0.25 51G1C = 1 51G1TD= 1.00
51G1CT= 0.00 51G1MR= 0.00
51G2P = 0.25 51G2C = 13 51G2TD= 1.00
51G2CT= 0.00 51G2MR= 0.00
27P1P = OFF 27P2P = OFF 59P1P = 104.0 59P2P = OFF
59N1P = OFF 59N2P = OFF 59QP = OFF 59V1P = OFF
27SP = OFF 59S1P = OFF 59S2P = OFF 27PP = OFF
59PP = OFF
Press RETURN to continue
27B81P= 80.0 81D1P = OFF 81D1D = 6.00
81D2P = OFF 81D2D = 2.00 81D3P = OFF 81D3D = 2.00
81D4P = OFF 81D4D = 2.00 81D5P = OFF 81D5D = 2.00
81D6P = OFF 81D6D = 2.00
79OI1 = 300.00 79OI2 = 600.00 79OI3 = 600.00 79OI4 = 0.00
79RSD = 1800.00 79RSLD= 600.00 79CLSD= 300.00
DMTC = 5
PDEMP = OFF NDEMP = OFF GDEMP = OFF QDEMP = OFF
TDURD = 4.00 CFD = 15.00 3POD = 1.50 50LP = 0.05
SV1PU = 0.00 SV1DO = 0.00 SV2PU = 0.00 SV2DO = 0.00
SV3PU = 0.00 SV3DO = 0.00 SV4PU = 0.00 SV4DO = 0.00
SV5PU = 0.00 SV5DO = 0.00 SV6PU = 0.00 SV6DO = 0.00
SV7PU = 900.00 SV7DO = 0.00 SV8PU = 0.00 SV8DO = 0.00
SV9PU = 900.00 SV9DO = 0.00 SV10PU= 0.00 SV10DO= 0.00
SV11PU= 900.00 SV11DO= 0.00 SV12PU= 0.00 SV12DO= 0.00
SV13PU= 0.00 SV13DO= 0.00 SV14PU= 0.00 SV14DO= 0.00
Continued on Next Page
