Date Code 990215 Serial Port Communications and Commands 10-29
SEL-351P Manual Técnico
Continued from Previous Page
SV15PU= 0.00 SV15DO= 0.00 SV16PU= 0.00 SV16DO= 0.00
OPPH = 2 OPGR = 2 OPLKPH= 4 OPLKGR= 4
OPLKSF= OFF HITRPH= OFF HITRGR= OFF HILKPH= OFF
HILKGR= OFF ECOLDP = N ECOLDG = N RPPH = N
Press RETURN to continue
RPGR = N RPSEF = N ESEQ = N PRECED= N
=>
=>>SHO EZ <ENTER>
EZ Group 1
Control Identifier (30 chars) RECLOSER R1
Circuit Identifier (30 chars) FEEDER 2101
CT Ratio (1-6000) 200.0
PT Ratio (1-10000) 100.0
Min. trip - phase (OFF,100.00-3199.99 A pri.) 200.00
Min. trip - ground (OFF,5.00-3199.99 A pri.) 50.00
Min. trip - SEF (OFF,5.00-159.99 A pri.) OFF
Fast curve - phase
(OFF,U1-U5,C1-C5,recloser or user curve) A
Fast curve - ground
(OFF,U1-U5,C1-C5,recloser or user curve) 1
Delay curve - phase
(OFF,U1-U5,C1-C5,recloser or user curve) C
Delay curve - ground
(OFF,U1-U5,C1-C5,recloser or user curve) 13
Operations - phase fast curve (OFF,1-5) 2
Operations - ground fast curve (OFF,1-5) 2
Operations to lockout - phase (OFF,2-5) 4
Operations to lockout - ground (OFF,2-5) 4
Reclose interval 1 (0-999999.00 cycles) 300.00
Reclose interval 2 (0-999999.00 cycles) 600.00
Reclose interval 3 (0-999999.00 cycles) 600.00
Press RETURN to continue
Reset time for auto-reclose (0-999999.00 cycles) 1800.00
Reset time from lockout (0-999999.00 cycles) 600.00
Close power wait time (OFF,0-999999.00 cycles) 300.00
Complex fast curve - phase (Y/N) N
Complex fast curve - ground (Y/N) N
Complex delay curve - phase (Y/N) N
Complex delay curve - ground (Y/N) N
High current trip - phase (Y/N) N
High current trip - ground (Y/N) N
High current lockout - phase (Y/N) N
High current lockout - ground (Y/N) N
Cold load pickup scheme (Y/N) N
Sequence coordination (Y/N) N
Underfrequency loadshedding (Y/N) N
Demand meter time constant (5,10,15,30,60 min) 5
=>>
