10-30 Serial Port Communications and Commands Date Code 990430
SEL-351P Manual Técnico
=>>SHO FZ <ENTER>
Global EZ Settings:
System Frequency (50,60 Hz) 60
Phase Rotation (ABC,ACB) ABC
Recloser Wear Monitor (AUTO,Y,N) AUTO
Interrupt rating (6000, 8000, 12000 A pri.) 6000
Reset trip-latched LEDs when recloser closes (Y,N) Y
True three-phase voltage connected (Y,N) N
Battery Amp-hours (6.5-20.0) 8.0
% Battery capacity for sleep (0-100) 20
Turn on the 12 V power (Y,N) N
SF6 low pressure warning threshold (0.9-2.0 atm) 1.1
=>>
=>>SHO G <ENTER>
Global Settings:
TGR = 0.00 NFREQ = 60 PHROT = ABC
DATE_F= MDY FP_TO = 15
LER = 15 PRE = 4
IN101D= 0.50 IN102D= 0.50 IN103D= 0.50 IN104D= 0.50
IN105D= 0.50 IN106D= 0.50
EBMON = Y COSP1 = 30000 COSP2 = 10000 COSP3 = 100
KASP1 = 0.27 KASP2 = 0.50 KASP3 = 6.00
LED11L= N LED12L= N LED13L= N LED14L= Y
LED15L= Y LED16L= Y LED17L= Y LED18L= N
LED19L= N LED20L= N LED24L= Y LED25L= Y
RSTLED= Y PB8D = 0.00 PB9D = 0.00 3PVOLT= N
EZGRPS= 2 AMPHR = 8.0 SLPCAP= 20 ON12V = N
ABAUD = 2400 CHWAKE=ABCD SF6PRS= 1.1
=>>
=>>SHO L <ENTER>
SELogic group 1
SELogic Control Equations:
TR =51P1T + 51P2T + 51G1T + 51G2T + 51N1T + 51N2T + 67P2T + 67G2T
+ 67N2T + 67N3T + 81D1T + PB9 + OC
TRCOMM=0
TRSOTF=0
DTT =0
ULTR =1
PT1 =0
LOG1 =0
PT2 =0
LOG2 =0
BT =0
52A =WB52A
CL =(PB8 * LT4 + CC) * LT7 * TRCAP * CLCAP
ULCL =TRIP + WBTRT + !(LT7 + WBCL) + !(LT4 + WBCL + CC + 79CY)
79RI =TRIP
Continued on Next Page
