Date Code 990215 Serial Port Communications and Commands 10-31
SEL-351P Manual Técnico
Continued from Previous Page
79RIS =52A + 79CY
79DTL =67N3T * OLS + (67P1 + 67G1 + 67N1) * TRIP + (!LT2 + !LT7) * (TRIP + !52A)
+ SV16 + PB9 + OC + 81D1T
Press RETURN to continue
79DLS =79LO
79SKP =0
79STL =TRIP
79BRS =51P1 + 51P2 + 51G1 + 51G2 + 51N1 + 51N2 + 67N3 + TRIP
79SEQ =79RS * SEQC * (51P1 + 51G1 + 51N1)
79CLS =TRCAP * CLCAP * !NOBATT * BCBOK * !DTFAIL
SET1 =PB1 * !LT1 * LT4
RST1 =PB1 * LT1 * LT4
SET2 =PB2 * !LT2 * LT4
RST2 =PB2 * LT2 * LT4 + !(79RS + 79CY + 79LO)
SET3 =PB3 * !LT3 * LT4
RST3 =PB3 * LT3 * LT4
SET4 =PB5 * !LT4
RST4 =PB5 * LT4
SET5 =PB6 * !LT5 * LT4
RST5 =PB6 * LT5 * LT4
SET6 =PB7 * !LT6 * LT4
RST6 =PB7 * LT6 * LT4
SET7 =1
RST7 =0
Press RETURN to continue
SET8 =0
RST8 =0
67P1TC=HLP
67P2TC=HTP
67P3TC=1
67P4TC=1
67N1TC=HLG * LT1
67N2TC=HTG * LT1
67N3TC=LT5 * !(51P1 + 51P2 + 51G1 + 51G2 + 51N1 + 51N2) * (!SV12 + SV12
* 50G5 + SV12 * 50N5)
67N4TC=1
67G1TC=HLG * LT1
67G2TC=HTG * LT1
67G3TC=1
67G4TC=1
67Q1TC=1
67Q2TC=1
67Q3TC=1
67Q4TC=1
51P1TC=!SV8 * OCP
Press RETURN to continue
51N1TC=!SV10 * OCG * LT1
51G1TC=!SV10 * OCG * LT1
51P2TC=!SV8 + SV8 * 50P5
51N2TC=(!SV10 + SV10 * 50G5 + SV10 * 50N5) * LT1
51G2TC=(!SV10 + SV10 * 50G5) * LT1
51QTC =1
SV1 =0
SV2 =0
SV3 =0
SV4 =0
SV5 =52A * (SV8 + SV10 + SV12) * (RPP + RPG + RPS)
Continued on Next Page
