10-32 Serial Port Communications and Commands Date Code 990215
SEL-351P Manual Técnico
Continued from Previous Page
SV6 =!52A * (79LO + !79RS * !79CY * !79LO) * (CLP + CLG)
SV7 =52A * !50P6 * SV8
SV8 =(SV8 + SV6T) * !(SV7T + SV5T * RPP + !CLP)
SV9 =52A * !50G6 * !50N6 * SV10
SV10 =(SV10 + SV6T) * !(SV9T + SV5T * RPG + !CLG)
SV11 =52A * !50N4 * SV12
SV12 =(SV12 + SV6T) * !(SV11T + SV5T * RPS + !CLG)
SV13 =51P1T + 51P2T + 51G1T + 51G2T + 51N1T + 51N2T + 67P2T + 67G2T
+ 67N2T
Press RETURN to continue
SV14 =50G6 + 50N6 + 51N1 + 51N2
SV15 =/SV13 * (OLG * GTP * SV14 + OLG * !GTP * SV14 * !50P6 + OLP * !GTP
* 50P6 + OLP * GTP * 50P6 * !SV14)
SV16 =SV15 + SV13 * OLP * OLG
OUT101=0
OUT102=0
OUT103=0
OUT104=0
OUT105=0
OUT106=0
OUT107=0
LED1 =LT1
LED2 =LT2
LED3 =0
LED4 =!SG1
LED5 =!LT4
LED6 =LT5
LED7 =0
Press RETURN to continue
LED8 =52A
LED9 =!52A
LED11 =59A1
LED12 =NOBATT + !BCBOK + DTFAIL
LED13 = !LT7
LED14 =TRIP
LED15 =51P1T + 51G1T + 51N1T
LED16 =67P2T + 67G2T + 67N2T
LED17 =81D1T
LED18 =79RS
LED19 =79CY
LED20 =79LO
LED24 =50G6 + 50N6 + 51N1 + 51N2
LED25 =67N3T
DP1 =0
DP2 =0
DP3 =0
DP4 =0
DP5 =0
DP6 =0
Press RETURN to continue
DP7 =0
DP8 =0
SS1 =PB4 * LT4 * !SG1
SS2 =PB4 * LT4 * SG1
SS3 =0
SS4 =0
Continued on Next Page
