USER MANUAL (Instruction for Use) SW 6.1
Treatment Selection
Version 6.1.6 dated 2020-01-31 EN Page 161 of 201
Figure 8-19: Result – Static Cyclotorsional Correction
IMPORTANT NOTE
The measurement range for the Static Cyclotorsional Correction is ± 12.5
degrees.
The SCC measurement is based on significant points in the upper part of the
human eye, for example blood vessels or structures of the iris.
It means the AMARIS system starts to search from the edge of the pupil to the
periphery of the iris including the limbus. The eye tracker searches for each
significant reference point in the measurement range.
If those points are similar to OD and OS the SCC measurement can still
provide an offset angle. This is NORMAL.
Please note that the SCC measurement can't be used to detect the correct
eye.
To proceed with the treatment procedure after the static cyclotorsion measurement was
successful, please lift the flap now and bring the particle aspiration system into treatment
position.
