USER MANUAL (Instruction for Use) SW 6.1
Device / System Description
Version 6.1.6 dated 2020-01-31 EN Page 63 of 201
WARNING!
Risk of injury!
Never use the patient bed for transport of patients!
The patient bed is designed for patients with a maximum weight of 150 kg!
IMPORTANT NOTE
Use only patient beds approved by SCHWIND eye-tech-solutions.
For detailed information concerning the patient bed operation refer to the User Manual of the
SCHWIND Patient Bed.
4.13 Foot Switch
The foot switch is used to start the treatment or test procedures. This switch has two switch
points to avoid unintentional release of pulses. The treatment procedure can be interrupted at
any time by releasing the foot switch. The program remains active, so the treatment can be
continued at any time by pressing the foot switch again.
4.14 Optional Features
4.14.1 Video System
The video system is an optional feature and can be ordered separately.The system will include
an additional observer camera.
For description and operation instructions of the video equipment please refer to the respective
manufacturers/suppliers instruction and operation manuals.
The interface (connection) to the AMARIS laser is described in chapter 2.9.2, Connection Terminal
Label of the Device.
The connector for connection of recording or display screen is labelled with “X4”. It is a standard
BNC connector.
A monitor for display of the camera video is optional available.
Additionally a Video Extender HDMI to connect displays via HDMI directly is available. Please
refer to chapter 4.13.11 Video Extender HDMI for detailed information.
Alternatively, a digital video recording system is available when the AMARIS system is equipped
with the latest Panel PC version (Onyx Zeus).
Digital video files are stored on the hard disk of the AMARIS panel PC. For description of viewing
and external export of video files, refer to chapter 7.11, Printout and Video (Export of Treatment
PDF and Video). When using the digital video recording option, addition external recording
devices are not needed.
