SCHWIND Amaris 500E - Keyboard with Card Reader, Touch Pad and Re-Sterilisable Pen; Figure 6-2: AMARIS 500 E with Key Switch and Emergency Stop; Figure 6-3: Keyboard with Touch Pad, Two Re-Sterilisable Pens and Card Reader

USER MANUAL (Instruction for Use) SW 6.1
Device Control and Operation
Version 6.1.6 dated 2020-01-31 EN Page 94 of 201
Figure 6-2: AMARIS 500E with key switch and emergency stop
6.2.1 Keyboard with Card Reader, Touch Pad and Re-sterilisable Pen
Figure 6-3: Keyboard with touch pad, two re-sterilisable pens and card reader
The re-sterilisable pen can be used to operate the touch screen of the panel PC under sterile
conditions. For instructions and parameters of sterilisation please refer to the SCHWIND
document “Reprocessing Instructions for resterilisable SCHWIND Products”.
Main Switch
Emergency Stop
Key Switch
Control Panel
Fluence Sensor Connector
