USER MANUAL (Instruction for Use) SW 6.1
Safety
Version 6.1.6 dated 2020-01-31 EN Page 34 of 201
The max. output load for all connected components (e.g. TFT-monitor, patient bed) is limited.
Refer to chapter 2.9.2 Connection Terminal Label of the Device.
Main Power
Supply
AMARIS
SCHWIND
AMARIS Type
Max. Load at
Power
Outlet
Socket –X1
Connections of Components to Power
Outlet Socket –X1
230V AC from
UPS
AMARIS,
AMARIS 500E,
AMARIS 750S,
AMARIS 1050RS
450VA
Connection and operation of SCHWIND
Patient Bed and monitor is possible.
208, 220,
230,240V AC
120, 127V AC
100, 110V AC
AMARIS,
AMARIS 500E
100, 110V AC
AMARIS 750S,
AMARIS 1050RS
20VA
Connection of SCHWIND Patient Bed
only. No connection of other devices to
the power outlet socket.
For use of SCHWIND Patient Bed, the
interlock cable must be installed and
Patient Bed must be locked during
treatment. 20VA is the standby power
supply of the Patient Bed.
Table 1: MAXIMAL LOAD AT POWER OUTLET X1
CAUTION
Do not overload the laser’s power outlet socket!
The maximum load for all connected components together must not exceed the
value(s) as listed in the Table 1: MAXIMAL LOAD AT POWER OUTLET X1 .
WARNING!
Risk of electric shock!
To avoid the risk of electric shock, the AMARIS must only be connected to
supply mains with protective earth.
Risk of reduced level of safety!
Connecting electrical equipment to the multiple socket outlet, effectively leads
to creating a MEDICAL ELECTRICAL SYSTEM and the result can be a reduced
level of safety. Connect only electrical equipment as approved system
combinations specified in chapter 4.15 .
For other electrical equipment than those specified, requirements must be
provided that are applicable to a MEDICAL ELECTRICAL SYSTEM. For this
purpose contact the manufacturer and refer to IEC 60601-1.
