SCHWIND Amaris 500E - Plume Evacuation System; Description; Plume Evacuation System - INTERNAL Version

USER MANUAL (Instruction for Use) SW 6.1
Device / System Description
Version 6.1.6 dated 2020-01-31 EN Page 59 of 201
Symbol explanation:
The component/unit may be used until: Date [year, four-digit] [month in two
digits] 5 years starting from date of packing .
28 days
Period after Opening: After opening the primary packing the product may be
used for a maximum of 28 days
Manufacturer
The product is not sterile
Lot-Number (and serial number)
BARCODE
EAN128
Bar codes according to EAN-128 standard, used for item no. and LOT no.
4.11 Plume Evacuation System
4.11.1 Description
The Plume Evacuation System with the single-channel nozzle is a system for debris removal
during the ablation process which can be installed instead of the existing particle aspiration
system.
As an alternative to the partical aspiration system (refer to chapter 4.10 Particle Aspiration
System) delivered with an AMARIS, a high efficacy Plume Evacuation System that is a default
system in the AMARIS 750S and AMARIS 1050RS models since July 2017. It will remove particles
from the ablation area and reduce the smell during surgery to a minimum and is mounted in two
variations:
Plume Evacuation System - INTERNAL version
(Standard for AMARIS 750S /1050RS)
The system consists of an internal evacuation unit (suction unit) with an integrated filter, tubing
(vacuum hose) and the single-channel evacuation nozzle, Figure 4-7 and parts for electrical
connection inside the AMARIS 750S or 1050RS, available from July 2017.
The internal version of the plume evacuator is not available for the AMARIS 500E
