USER MANUAL (Instruction for Use) SW 6.1
Installation
Version 6.1.6 dated 2020-01-31 EN Page 79 of 201
Device Dimensions - SCHWIND AMARIS 500E
Figure 5-6: AMARIS 500E – front view
Figure 5-7: AMARIS 500E – side view
Drawing is not shown in actual size
