USER MANUAL (Instruction for Use) SW 6.1
Installation
Version 6.1.6 dated 2020-01-31 EN Page 75 of 201
5.2.2 Device and Room Dimensions
IMPORTANT NOTE
Keep a distance to wall for service works as specified in the following drawings.
Device Dimensions - AMARIS / AMARIS 750S / AMARIS 1050RS
Figure 5-1: AMARIS / AMARIS 750S/ AMARIS 1050RS with swivelling patient bed - front view
Figure 5-2: AMARIS / AMARIS 750S/AMARIS 1050RS with swivelling patient bed - side view
