Section 01 MAINTENANCE
Subsection 01 (MAINTENANCE SCHEDULE)
FIRST 10 HOURS
25 HOURS OR 3 MONTHS
50 HOURS or 6 MONTHS
100 HOURS or 1 YEAR
200HOURSor2YEAR
A: Adjust
C: Clean
I: Inspect
L: Lubricate
R: Replace
O: Operator
D: Dealer
TO BE PERFORMED BY
PART/TASK NOTE
ELECTRICAL SYSTEM
Spark plug I I R D
Electrical connections and fastening (ignition system, starting
system, fuel injectors etc.)
IID
D.E.S.S. key/post
(5)
IID
Monitoring beeper I I D
Battery and fasteners I I
(6)
D
(5) Inspect operation before each ride.
(6) Inspect once a month. Add
electrolyte as required.
STEERING SYSTEM
Steering cable and connections I I D
Steering nozzle bushings I I D
O.T.A.S.
(10)
IID
iTC and iBR levers
(5) (7)
I,
L
D
(5) Inspect operation before each ride.
(7) See NOTE 2 after
maintenance schedule.
(10) Check operation.
PROPULSION SYSTEM
Carbon ring and rubber boot (drive shaft) I I D
Impeller boot I I D
Impeller shaft seal, sleeve and O-ring I
(4)
D
Drive shaft/impeller splines I, L D
Sacrificial anode (if so equipped)
(8)
D
Impeller and impeller wear ring clearance I I D
Pump mounts I I D
(4) At storage period or
after 100 hours of use
whichever comes first.
(8) Inspect each month (more
often in salt water use) and change
when necessary.
iBR SYSTEM (intelligent Brake/Reverse)
iBR gate backlash I I D
iBR support plates I I D
iBR friction sleeves I R D
iBR connecting arms, sleeves, and bushings I I D
iBR U lever, VTS trim ring, iBR gate and bushings I I D
iBR locking sleeve I R D
iBR protective guard I I D
—
iS SYSTEM (intelligent Suspension)
iS fluid
(9)
IID
iS position sensor I I D
(9) Check pump reservoir fluid level
and check for system leaks.
2 smr2009-011
