Section 05 ELECTRICAL SYSTEM
Subsection 07 (GAUGE)
6. Install the diagnostic connector in its holder.
7. Carry out the following procedure:
TESTING
DEPTH SOUNDER OPERATION
.
Testing Depth Sounder Operation
1. Press START/STOP button.
2. Install the D.E.S.S. key on the D.E.S.S. post.
3. Check information center to confirm depth
sounder operation. The depth sounder icon
is visible in the information center when the
depth sounder is detected.
ssi2009-
002-018_a
1. Depth sounder icon
4. Reinstall all other removed parts.
5. Launch watercraft in water and check depth
sounder operation. Refer to
INFORMATION
CENTER
for instructions on how to select the
DEPTH
indication in numerical display.
WARNING
Never use the depth gauge as a warning de-
vice to ride in shallow water. Use it as a nav-
igation guide only. Not to be used to get pre-
cise navigation data.
smr2009-036 357
