Section 08 TECHNICAL SPECIFICATIONS
Subsection 01 (RXT iS 255/GTX LIMITED iS 255)
MODEL RXT iS 255 GTX LIMITED iS 255
ENGINE (cont'd)
Connecting rod small end radial play Wear limit 0.080 mm (.0031 in)
New 22.996 mm to 23.000 mm (.9054 in to .9055 in)
Piston pin diameter
Wear limit 22.990 mm (.9051 in)
New 31.980 mm to 32.000 mm (1.2591 in to 1.2598 in)
Balance shaft journal diameter
Wear limit 31.950 mm (1.2579 in)
Balance shaft radial clearance Wear limit 0.070 mm (.0028 in)
Balance shaft axial clearance New 0.020 mm to 0.250 mm (.0008 in to .0098 in)
New 14.460 mm to 14.500 mm (.5693 in to .5709 in)
Supercharger shaft driven plate
journal depth
Wear limit 14.600 mm (.5748 in)
New 11.000 mm to 11.050 mm (.4331 in to .435 in)
Supercharger drive gear thickness
Wear limit 10.900 mm (.4291 in)
New 4.050 mm to 4.150 mm (.1594 in to .1634 in)
Supercharger lock washer thickness
Wear limit 3.950 mm (.1555 in)
New 10.900 mm to 10.700 mm (.4291 in to .4213 in)
Supercharger spring washer package
height (not compressed)
Wear limit 10.200 mm (.4016 in)
AIR INTAKE SYSTEM
Intake spark arrester Tubular, wire screen
COOLING SYSTEM
Type Closed loop cooling system
Coolant
Ethylene-glycol and distilled water (50%/50%). Use premix coolant
from BRP or a coolant specially formulated for aluminum engines
Cooling system capacity 5.5 L (5.8 qt (U.S. liq.)) total
Thermostat 87°C (189°F)
Monitoring beeper setting 100°C (212°F)
EXHAUST SYSTEM
Type
D-Sea-Bel sound reduction system. Water cooled/water injected
(open lo
op). Direct flow from jet pump
Water in
jection in muffler
3x3.5mm
(.138 in) on exhaust pipe and 1 x 3.5 mm (.138 in) on muffler
FUEL SYS
TEM
Fuel injection type
Multip
oint fuel injection with iTC (intelligent Throttle Control).
Single throttle body (60 mm) with an actuator
Fuel pressure 386 kPa to 414 kPa (56 PSI to 60 PSI)
Fuel injector Quantity
3
Inside North America ((RON + MON)/2) 91 or higher
Fuel type
Outside North America (RON) 95 or higher
Fuel tank (including reserve) 70 L (18.5 U.S. gal.)
Fuel tank reserve (from low level signal) approx. 14 L (3.7 U.S. gal.)
Idle speed 1800 ± 50 RPM (not adjustable)
smr2009-044 513
