Sea-doo RXT iS 255 2009 User Manual

Section 09 WIRING DIAGRAM
Subsection 01 (WIRING DIAGRAM INFORMATION)
smr2009-045-007_a
1. CAN wire
2. Wire destination
FB2: Fuse box #2
C7: Terminal C7 in fuse box #2
On the wiring diagram, corresponding CAN links
are identified in fuse box #2 using the following
coding.
smr200
9-045-008_a
1. CAN wire
2. Wire origin
3. Destin
ation terminal (was referenced at ECM)
Fuse Box Terminal Reference
Refer t
o
POWER DISTRIBUTION subsection.
518 smr2009-044
