Section 02 ENGINE
Subsection 04 (SUPERCHARGER)
NOTICE
Not installing the tool as shown will
change the torque applied to the screw. Proper
torque and tightening sequence are important.
6. After complete installation of the supercharger,
the slipping moment has to be rechecked.
Refer to
SUPERCHARGER CLUTCH SLIPPING
MOMENT (ON ENGINE)
at the beginning of
this subsection.
52 smr2009-020
